CPU Mobile Intel® Pentium® III Processor 1GHz-M (w/ SpeedStep®)
Secondary Cache 512KB
Memory 512MB SDRAM, max. 1024MB (PC133) 256MB SDRAM, max. 1024MB (PC133)
Hard Disk Drive 40GB (Ultra DMA/100 and S.M.A.R.T. support) 30GB (Ultra DMA/100 and S.M.A.R.T. support)
BIOS ROM 1024KB Flash Memory
Chipset Intel® 830MG
Display 13.3" XGA TFT colour (Max. 1024 x 768 pixels)
Graphics Integrated VGA (Max.48MB w/IDMS) with 3D Graphics Accelerator and MPEG-2 Support (for DVD)
Sound AC Link Audio (AC97 compliance: Sigma Tel STAC9767 codec), Internal Speakers (Stereo), Internal Microphone
Communication Integrated V.90 Modem & 10/100Mbps Base-T LAN
Wireless LAN 802.11b Wi-Fi Compliant Module Upgradable (Built-in Antenna)¢Ó
Bluetooth¢â PCMCIA Option
Storage Device External USB FDD (Optional)
Mobile Slot
(Hot swappable)		 Combo Drive (DVD & CD-R/RW) CD-R/RW Drive
Replaceable with options:
2nd Battery (6 Cells, Li-Ion, 10.8V, 3400mAH), DVD Drive, PC Card Slot, Weight Saver, SuperDisk LS240, 2nd Hard Disk (15/30GB)
External I/O Interface 1x VGA, 2 x USB, 1 x RJ11, 1 x RJ45, 1x IEEE1394, Audio (Line-in, Headphone-out, Microphone-in), AC Adapter Power Input, Docking for Port Replicator
Port Replicator

1 x VGA, 2 x PS/2 Keyboard/Mouse Port, 1 x Serial, 1 x Parallel,1 x USB, 1 x Ext FDD, 1 x RJ45, AC Adapter Power Input
IR Interface IrDA1.1 ( Max. 4Mbps )
Security Panel

Application Mode : Programmable launch buttons for Internet, email and two other software applications
 Security Mode : Unique numeric buttons for security lock (More than 800,000 possible password combinations)
Keyboard Key Pitch 19mm, Key Stroke 3mm
Pointing Device Touch Pad with Scroll Button
PCMCIA Interface Type I or II x 1 slot
AC Adapter Input: AC100-240V, Output: DC16V 3.75A
Battery Approx. 3.5 hours * Li-Ion 10.8V 3400mAH
OS Bundled Microsoft® Windows® XP Home Edition
OS Supported Microsoft® Windows® 98 (2nd Edition )
Microsoft® Windows® Millennium Edition
Microsoft® Windows® 2000 Professional Edition
Microsoft® Windows® XP Home Edition
Microsoft® Windows® XP Professional Edition
Dimensions 293mm(W) x 236.5mm(D) x 26.5mm min(H)
Weight Approx. 1.7Kg ( with weight saver )

* Results obtained from Ziff Davis (BusinessWinstone 2001) BatteryMark Ver1.0. Actual battery life will vary based on screen brightness, applications, features, power management setting, battery conditioning, and other customer preferences. DVD or hard drive usage may also have a significant impact on battery life.

¢Ó Upgrade to Wireless LAN is only available in selected countries. Wireless LAN Module to be purchases separately. Please contact your local authorised service centre for purchase and applicability of upgrade.
